DWIN HMI LCD 4.3 Capacitive Touch, TFT Screen, intelligent display, 480*272, 330nit, DMG48270C043_05WTC
1,798.32
?This model is the intelligent LCD display module with a capacitive touch screen for user interactivity. It has onboard serial UART PORT which can be controlled by any microcontroller via a simple yet powerful command set. It can be used as TFT Display & Touch controller in various electronic equipment such as vending machines, currency counting machines, washing machines, and many other similar appliances.
?Features
- ?Based on self-designed T5L0, 16.7M Color, 18bit, 480*272, Cheap TV-TN-TFT-LCD
- No touch /Resistive touch/Capacitive touch screen Optional
- 232 Interface,10Pin1.0mm FCC connection wire
- Download via SD card or on-line serial port
- Easy-to-use DWIN DGUS V7.624 GUIs Development, no coding skills required;
- Dual Development System: DGUS II/ TA(Instruction set)
- Cost-Effective TN screen
- GST & Freight Extra at actual
-
